EKKO EB13CD Electric Fork-Over Walkie Stacker – 2,800 lb Capacity, 118" Lift, 82.3" Mast, Fixed Forks, 24V Maintenance Free Battery

EKKOModel EB13CDBrand new · Full warrantyBe the first to review

Free freight shipping · ships factory-direct from EKKO. Ship date confirmed by email within 1 business day.

Save $249.95

$4,999.00

$4,999.00 - $4,999.00

$4,999.00

$4,749.05

$4,749.05 - $4,749.05

$4,749.05

Delivery

Freight delivery FREEFree shipping on orders over $500 (lower 48) Pick up at the EKKO warehouse1761 W Holt Ave, Pomona, CA 91768

How will you unload it? Required

Forklift on siteRated for this unit's shipping weight Loading dock48–52″ high, reachable by a full-size freight truck Liftgate delivery +$150Driver lowers it to the ground. Needed for homes and sites without a dock or forklift.

Free freightorders over $500
Full warrantybrand new
30-day returnsdamage covered
Price matchauthorized dealers

Buying for a business? Pay by ACH or wire and skip card fees. Get wire details

EKKO · EB13CD

About the EB13CD

The EKKO EB13CD electric fork-over walkie stacker is built for tight spaces. It lifts 2,800 lb to 118" on a compact 71.7" chassis that turns in 55.1", and it weighs just 992 lb.

Powered by a 24V/85Ah (2×12V) maintenance-free battery with an internal 24V/15A charger, this electric fork-over stacker provides smooth travel and lift. Fixed forks and a fork-over base keep the chassis compact for stockrooms and narrow aisles.

From the manufacturer

The EKKO EB13CD Electric Fork-Over Stacker combines the capabilities of a forklift, reach truck and walkie stacker in a compact design. Its fork-over layout suits tight spaces and specialized loads, from loading and unloading trucks and busy docks to stockrooms and warehouse aisles.

Made from high-quality steel and components with durable drives built for daily use, impacts and directional changes. The steel frame is robotically welded. Charge the unit once a month, even when it is not in use.

Highlights

Load capacity 2,800 lbs with a 24" load center
118" maximum lift height for mid-level rack access
Fixed forks, 11.8" inner / 26.8" outer width, 45.28" long
82.3" lowered mast height
Ergonomic handle and polyurethane wheels for quiet, accurate moves
24V/85Ah (2×12V) maintenance-free battery with internal 24V/15A charger
EKKO warranty: 3 years on frame, mast and forks; 1 year on components

Specifications

Capacity & lift

Load capacity	2,800 lb
Max lift height	118 in
Load center	24 in

Dimensions

Turning radius	55.1 in
Overall length	71.7 in
Extended mast height	147.6 in
Lowered mast height	82.3 in

Power & drive

Battery	24V / 85Ah (2 × 12V) maintenance-free
Charger	24V / 15A
Lift motor	2.2 kW
Drive motor	0.75 kW

Forks & chassis

Fork length	45.28 in
Fixed fork width (inner / outer)	11.8 / 26.8 in
Lowered fork height	3.54 in
Wheels	Polyurethane

General

Model	EB13CD
Service weight	992 lb
Warranty	3 yr frame, mast & forks · 1 yr components

Manuals & downloads

⛟Shipping & deliveryFree freight shipping · ship date confirmed in 1 business day

Free freight shipping on orders over $500 to the 48 contiguous states; orders under $500 ship for a flat $150. Remote areas are quoted before you pay.

Machines ship factory-direct. We confirm stock and your ship date by email within 1 business day; transit is typically 3–7 business days and the carrier calls ahead to schedule.

You unload with a forklift or loading dock. No dock? Choose liftgate delivery (+$150) above. Or pick up free at the EKKO warehouse, 1761 W Holt Ave, Pomona, CA.

Inspect the crate before signing, note any damage on the delivery receipt, and report concealed damage within 3 business days.

✓Manufacturer warranty3-year frame, mast & forks · 1-year components · we handle claims for you

Every machine is brand new and covered by the EKKO Advantage Warranty. Coverage for the EB13CD:

3 yearsFrame, mast and forks
1 yearDrive and lift motors, controller, hydraulics, charger and battery (lithium or lead-acid)
30 daysWear items (tires, bulbs, rubber parts)

As an authorized EKKO dealer, we file and manage warranty claims with EKKO for you: send us a photo of the data plate and a photo or video of the problem and we take it from there. Coverage applies to the original purchaser under normal use and scheduled maintenance; wear, overloading, accidents and freight damage aren't covered.

Read the full warranty (PDF) →

↺30-day returnsDamaged or defective on arrival? We cover the freight.

Request a return within 30 days of delivery by phone or email. Equipment must come back in the condition it was received.

Returns of machines working as intended carry a 10% restocking fee and the customer pays return freight. If your equipment arrives damaged or becomes defective within 30 days, we cover return and replacement freight.

Read the full return policy →

$Price match guaranteeFound it lower from an authorized dealer? We'll match it.

If an authorized dealer advertises the identical model, configuration and warranty for less, we'll match that price, as long as it isn't below the manufacturer's minimum advertised price.

Ask before you order or within 7 days of your order date: call (844) 455-4327 or email support@equipmentnation.com with the dealer, link and price. Freight, taxes and fees are excluded.

Price match details →

☎Talk to an equipment expert(844) 455-4327 · Mon–Fri, 9–5 ET

Send us your load weight, lift height, aisle width and door clearances and we'll confirm this is the right machine before you buy. Call (844) 455-4327 or email support@equipmentnation.com.

ELECTRIC FORK-OVER WALKIE STACKER · EB13CD

FORK-OVER STACKER, 118-INCH LIFT

The EKKO EB13CD lifts 2,800 lb to 118" with a fork-over design, fixed forks and a light 992 lb service weight.

Capacity2,800 lbLift118″BatteryLead-acid 24V

2,800 lbCapacity

118″Lift

Lead-acid 24VBattery

NewFull manufacturer warranty

BUILT FOR THE JOB

A different chassis for tight spaces

The EB13CD takes a different approach from EKKO's straddle stackers. Its fork-over design places the base legs beneath the fixed forks instead of outside the pallet, which keeps the chassis narrow and the machine easy to place in stockrooms and tight aisles. It lifts 2,800 lb to 118" with an 82.3" lowered mast and 147.6" fully raised. Fixed forks sit at 11.8" inner and 26.8" outer width. At 992 lb service weight it is light for its class. A 24V/85Ah maintenance-free battery with a 24V/15A internal charger keeps it working with less downtime.

See full specifications

WHY THE EB13CD

ENGINEERED WHERE IT COUNTS.

2,800 lb to 118"

Rated for 2,800 lb at a 24" load center, with a maximum lift height of 118". Enough reach for mid-level rack positions and double-stacking in stockrooms. Fully raised, the mast extends to 147.6".

Maintenance-Free 24V Battery

A maintenance-free 2×12V/85Ah (24V) battery pack powers drive and lift. A built-in 24V/15A charger keeps charging simple, with no separate charger station to install. Charge it about once a month when it sits idle.

Fork-Over Compact Chassis

Fixed forks measure 11.8"/26.8" inner/outer width with 45.28" length. A 55.1" turning radius and 71.7" overall length keep the EB13CD easy to place in stockrooms and tight aisles.

Controls Built for Shifts

An ergonomic handle and responsive electric drive give accurate movement every shift. High-grade steel with robotic welding and polyurethane wheels deliver lasting, quiet performance on warehouse floors.

WHERE IT WORKS

MADE FOR YOUR OPERATION.

Stockrooms

Put away and pull inventory in back rooms where aisles are narrow and a counterbalanced forklift will not fit.

Retail backrooms

Stack incoming freight and pull seasonal stock in store backrooms with tight aisles and limited floor space.

Manufacturing floors

Feed raw material to workstations and lift parts bins to a comfortable working height beside the line.

Small warehouses

Give a small team real stacking capability without the cost, footprint or training load of a sit-down forklift.

COMPARE SIMILAR MODELS

FIND YOUR EXACT FIT.

	This itemEB13CD$4,749.05	EB13C-118$5,004.60	EB13E$5,299.10	EB13ES-Li$6,771.60
Capacity	2,800 lb	2,800 lb	2,800 lb	2,800 lb
Lift	118″	118″	119″	119″
Battery	Lead-acid 24V	Lead-acid 24V	Lead-acid 24V	Lithium 24V
Side shift	No	No	No	Yes
Shipping	Free	Free	Free	Free
	You're viewing this	View details	View details	View details

FROM CHECKOUT TO YOUR DOCK

ORDER. CONFIRM. DELIVER. WORK.

01
Order online
Pick your model and how you'll unload it. Pay by card, financing or ACH.
02
Ship date confirmed
We confirm stock and your ship date by email within 1 business day.
03
Freight delivery
Ships factory-direct from the manufacturer. The carrier calls ahead to schedule.
04
Inspect & sign
Check the crate before signing and note any damage. We handle the rest.

BEFORE YOU BUY

QUESTIONS ABOUT THE EB13CD.

Still unsure? Call (844) 455-4327 or email support@equipmentnation.com. Real people, Mon–Fri.

How much overhead clearance does the EB13CD need?

With the forks down, the EB13CD stands 82.3" tall at the mast, taller than a typical 80-inch interior door, so plan routes through dock doors and roll-ups. At full lift the mast extends to 147.6", so check ceiling, light and sprinkler clearance at the top of the lift. Call (888) 378-6244 with your measurements and we will confirm the fit.

What loads does the EB13CD handle with its fixed forks?

The EB13CD uses fixed forks set at 11.8"/26.8" inner/outer width, with a 45.28" fork length and a 24" load center rating. Lowered fork height is 3.54". If your pallets or skids vary widely in size, tell us their dimensions at (888) 378-6244 and we will confirm the fit or suggest an adjustable-fork model.

How is the EB13CD charged?

The EB13CD carries its charger on board: a 24V/15A unit matched to its maintenance-free 2×12V/85Ah (24V) battery. Park the machine, plug it in and charge; there is no separate charger station to buy or mount. If the unit sits unused, charge it about once a month to protect the battery.

What does fork-over mean on the EB13CD?

On a fork-over stacker, the base legs run beneath the forks rather than outside the load, as they do on a straddle stacker. That keeps the EB13CD compact, with a 71.7" overall length and a light 992 lb service weight. Because the legs sit under the forks, tell us your pallet type at (888) 378-6244 and we will confirm the fit before you order.

How long until it ships?

We confirm stock and your ship date by email within 1 business day. In-stock units usually leave the warehouse in 2–5 business days, then freight transit takes 3–7 business days.

Is shipping really free?

Yes, on orders over $500 to the 48 contiguous states (orders under $500 ship for a flat $150). You'll need a dock or forklift to unload; otherwise choose liftgate delivery (+$150).

Can I finance it?

Yes. Choose Shop Pay Installments or Affirm at checkout to spread payments out, or call us about ACH/wire for large orders.

CUSTOMER REVIEWS

OWNERS ON THE EB13CD.

No reviews yet. Customer reviews will appear here as they come in.

Questions before you buy? Call (844) 455-4327.

Own the EB13CD? Be the first to review it.

How does it handle your loads and lift heights?
How does the battery hold up over a full shift?
How was ordering, delivery and setup?
