EKKO EB13ES-Li Electric Walkie Stacker – 2,800 lb Capacity, 119" Lift, 82" Mast, Side Shift, Adjustable Forks, 24V Lithium Battery

EKKOModel EB13ES-LiBrand new · Full warrantyBe the first to review

Free freight shipping · ships factory-direct from EKKO. Ship date confirmed by email within 1 business day.

Save $356.40

$7,128.00

$7,128.00 - $7,128.00

$7,128.00

$6,771.60

$6,771.60 - $6,771.60

$6,771.60

Configure your EB13ES

Compare models

Capacity: 2,800 lb

2,800 lb Selected 2,640 lb 145″ only

Lift height: 119″

119″ Selected 145″ 2,640 only

Delivery

Freight delivery FREEFree shipping on orders over $500 (lower 48) Pick up at the EKKO warehouse1761 W Holt Ave, Pomona, CA 91768

How will you unload it? Required

Forklift on siteRated for this unit's shipping weight Loading dock48–52″ high, reachable by a full-size freight truck Liftgate delivery +$150Driver lowers it to the ground. Needed for homes and sites without a dock or forklift.

Free freightorders over $500
Full warrantybrand new
30-day returnsdamage covered
Price matchauthorized dealers

Buying for a business? Pay by ACH or wire and skip card fees. Get wire details

EKKO · EB13ES-Li

About the EB13ES-Li

The EKKO EB13ES-Li lithium walkie stacker adds side shift to a compact straddle chassis. It lifts 2,800 lb to 119", and the operator can shift the forks sideways to line up a rack opening without backing out and re-approaching.

Powered by a 24V/50Ah lithium battery with an internal 24V/15A charger, this electric straddle stacker provides smooth travel and lift. Side shift moves the forks sideways for final alignment at the rack.

From the manufacturer

The EKKO EB13ES-Li Lithium Straddle Stacker with Side Shift is designed to combine the versatility of a forklift, reach truck and walkie stacker. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing. Side shift adds precise load placement with less repositioning.

Made from high-quality steel and components with durable drives built for daily use, impacts and directional changes. The steel frame is robotically welded.

Highlights

Load capacity 2,800 lbs with a 24" load center
119" maximum lift height for mid-level rack access
Side shift for precise load placement
Adjustable forks 8.3"–33.5" for different pallet sizes
Adjustable legs 45.5"–59.1" for added stability
82" lowered mast height
Curtis controller for smooth, responsive operation
24V/50Ah lithium battery with internal 24V/15A charger
EKKO warranty: 3 years on frame, mast and forks; 1 year on components

Specifications

Capacity & lift

Load capacity	2,800 lb
Max lift height	119 in
Load center	24 in

Dimensions

Turning radius	52.6 in
Overall length	70 in
Max overall width	61 in
Extended mast height	135 in
Lowered mast height	82 in

Power & drive

Battery	24V / 50Ah Lithium
Charger	24V / 15A
Controller	Curtis
Lift motor	2.2 kW
Drive motor	0.75 kW
Travel speed (laden / unladen)	2.5 / 2.6 mph
Lift speed (laden / unladen)	18.1 / 26.8 ft/min
Lowering speed (laden / unladen)	22.0 / 19.3 ft/min

Forks & chassis

Fork length	45.3 in
Single fork width	4 in
Adjustable fork width	8.3–33.5 in
Lowered fork height	2.35 in
Fixed leg length	36.5 in
Adjustable leg width	45.5–59.1 in
Side shift	Yes
Wheels	Polyurethane

General

Model	EB13ES-Li
Service weight	1,635 lb
Warranty	3 yr frame, mast & forks · 1 yr components

Manuals & downloads

⛟Shipping & deliveryFree freight shipping · ship date confirmed in 1 business day

Free freight shipping on orders over $500 to the 48 contiguous states; orders under $500 ship for a flat $150. Remote areas are quoted before you pay.

Machines ship factory-direct. We confirm stock and your ship date by email within 1 business day; transit is typically 3–7 business days and the carrier calls ahead to schedule.

You unload with a forklift or loading dock. No dock? Choose liftgate delivery (+$150) above. Or pick up free at the EKKO warehouse, 1761 W Holt Ave, Pomona, CA.

Inspect the crate before signing, note any damage on the delivery receipt, and report concealed damage within 3 business days.

✓Manufacturer warranty3-year frame, mast & forks · 1-year components · we handle claims for you

Every machine is brand new and covered by the EKKO Advantage Warranty. Coverage for the EB13ES-Li:

3 yearsFrame, mast and forks
1 yearDrive and lift motors, controller, hydraulics, charger and battery (lithium or lead-acid)
30 daysWear items (tires, bulbs, rubber parts)

As an authorized EKKO dealer, we file and manage warranty claims with EKKO for you: send us a photo of the data plate and a photo or video of the problem and we take it from there. Coverage applies to the original purchaser under normal use and scheduled maintenance; wear, overloading, accidents and freight damage aren't covered.

Read the full warranty (PDF) →

↺30-day returnsDamaged or defective on arrival? We cover the freight.

Request a return within 30 days of delivery by phone or email. Equipment must come back in the condition it was received.

Returns of machines working as intended carry a 10% restocking fee and the customer pays return freight. If your equipment arrives damaged or becomes defective within 30 days, we cover return and replacement freight.

Read the full return policy →

$Price match guaranteeFound it lower from an authorized dealer? We'll match it.

If an authorized dealer advertises the identical model, configuration and warranty for less, we'll match that price, as long as it isn't below the manufacturer's minimum advertised price.

Ask before you order or within 7 days of your order date: call (844) 455-4327 or email support@equipmentnation.com with the dealer, link and price. Freight, taxes and fees are excluded.

Price match details →

☎Talk to an equipment expert(844) 455-4327 · Mon–Fri, 9–5 ET

Send us your load weight, lift height, aisle width and door clearances and we'll confirm this is the right machine before you buy. Call (844) 455-4327 or email support@equipmentnation.com.

LITHIUM WALKIE STACKER WITH SIDE SHIFT · EB13ES-Li

SIDE SHIFT ACCURACY, 119-INCH LIFT

The EKKO EB13ES-Li lifts 2,800 lb to 119" with side shift for fine horizontal placement, powered by a 24V/50Ah lithium battery.

Capacity2,800 lbLift119″BatteryLithium 24V

2,800 lbCapacity

119″Lift

Lithium 24VBattery

YesSide shift

NewFull manufacturer warranty

BUILT FOR THE JOB

Faster, cleaner placement in tight aisles

The EB13ES-Li adds side shift to a compact lithium straddle stacker. Operators line up the load with the rack opening by shifting the forks sideways, which saves repeated back-and-forth moves in narrow aisles. It lifts 2,800 lb to 119" with an 82" lowered mast, the same height as the EB13E-Li, so it suits mid-level racking and stockrooms. Forks adjust from 8.3" to 33.5" and legs from 45.5" to 59.1". The 24V/50Ah lithium battery with built-in 24V/15A charger simplifies uptime. It is a strong pick for teams that value placement speed over maximum height.

See full specifications

WHY THE EB13ES-LI

ENGINEERED WHERE IT COUNTS.

2,800 lb to 119"

Rated for 2,800 lb at a 24" load center, with a maximum lift height of 119". Enough reach for mid-level rack positions and double-stacking in stockrooms. Fully raised, the mast extends to 135".

24V Lithium Power

A 24V/50Ah lithium battery runs both drive and lift. The 24V/15A charger is built in, so there is no separate charging station to buy, mount or wire.

Adjustable Forks and Legs

Forks adjust from 8.3" to 33.5" and straddle legs from 45.5" to 59.1", so one machine handles mixed pallet sizes. A 52.6" turning radius and 70" overall length keep it nimble in narrow aisles.

Side Shift for Precision

Side shift moves the forks sideways, so operators line up rack slots without repositioning the whole machine. A Curtis controller, ergonomic tiller and polyurethane wheels keep moves smooth.

WHERE IT WORKS

MADE FOR YOUR OPERATION.

Tight rack slots

Side shift trims pallet alignment at height, so loads go into snug rack openings without repositioning the machine.

Stockrooms

Put away and pull inventory in back rooms where aisles are narrow and a counterbalanced forklift will not fit.

Pallet racking

Place and retrieve pallets up to 119" in standard warehouse racking, walking the load straight into the bay.

Retail backrooms

Stack incoming freight and pull seasonal stock in store backrooms with tight aisles and limited floor space.

COMPARE SIMILAR MODELS

FIND YOUR EXACT FIT.

	This itemEB13ES-Li$6,771.60	EB13C-98Li$5,593.60	EB13E-138Li$5,888.10	EB13CD$4,749.05
Capacity	2,800 lb	2,800 lb	2,800 lb	2,800 lb
Lift	119″	98″	138″	118″
Battery	Lithium 24V	Lithium 24V	Lithium 24V	Lead-acid 24V
Side shift	Yes	No	No	No
Shipping	Free	Free	Free	Free
	You're viewing this	View details	View details	View details

FROM CHECKOUT TO YOUR DOCK

ORDER. CONFIRM. DELIVER. WORK.

01
Order online
Pick your model and how you'll unload it. Pay by card, financing or ACH.
02
Ship date confirmed
We confirm stock and your ship date by email within 1 business day.
03
Freight delivery
Ships factory-direct from the manufacturer. The carrier calls ahead to schedule.
04
Inspect & sign
Check the crate before signing and note any damage. We handle the rest.

BEFORE YOU BUY

QUESTIONS ABOUT THE EB13ES-LI.

Still unsure? Call (844) 455-4327 or email support@equipmentnation.com. Real people, Mon–Fri.

How much overhead clearance does the EB13ES-Li need?

With the forks down, the EB13ES-Li stands 82" tall at the mast, taller than a typical 80-inch interior door, so plan routes through dock doors and roll-ups. At full lift the mast extends to 135", so check ceiling, light and sprinkler clearance at the top of the lift. Call (888) 378-6244 with your measurements and we will confirm the fit.

What pallet sizes does the EB13ES-Li handle?

The forks adjust from 8.3" to 33.5" overall width with 45.3" fork length, and the straddle legs adjust from 45.5" to 59.1". Set the legs to clear the pallet and the forks to its entry openings, and the EB13ES-Li handles a wide range of pallets and skids. Capacity is 2,800 lb at a 24" load center. Unsure about an odd size? Call (888) 378-6244.

How is the EB13ES-Li charged?

The EB13ES-Li carries its charger on board: a 24V/15A unit matched to its 24V/50Ah lithium battery. Park the machine, plug it in and charge; there is no separate charger station to buy or mount. Lithium also means no battery watering routine.

Should I choose the EB13ES-Li or the EB13ES-145Li?

Both have side shift, a 24V/50Ah lithium battery, a 24V/15A charger and a 52.6" turning radius. The EB13ES-Li lifts 2,800 lb to 119" with an 82" lowered mast. The EB13ES-145Li lifts 2,640 lb to 145" with a 95.7" lowered mast. Choose the EB13ES-Li for heavier loads at mid height, the 145Li for top positions.

How long until it ships?

We confirm stock and your ship date by email within 1 business day. In-stock units usually leave the warehouse in 2–5 business days, then freight transit takes 3–7 business days.

Is shipping really free?

Yes, on orders over $500 to the 48 contiguous states (orders under $500 ship for a flat $150). You'll need a dock or forklift to unload; otherwise choose liftgate delivery (+$150).

Can I finance it?

Yes. Choose Shop Pay Installments or Affirm at checkout to spread payments out, or call us about ACH/wire for large orders.

CUSTOMER REVIEWS

OWNERS ON THE EB13ES-LI.

No reviews yet. Customer reviews will appear here as they come in.

Questions before you buy? Call (844) 455-4327.

Own the EB13ES-Li? Be the first to review it.

How does it handle your loads and lift heights?
How does the battery hold up over a full shift?
How was ordering, delivery and setup?

EQUIPMENT NATION

THE DEALER THAT PICKS UP THE PHONE.

We sell brand-new material handling equipment from leading manufacturers, shipped factory-direct with the full manufacturer warranty. Before you buy, a real equipment specialist will check your load, lift height and aisles so you get the right machine the first time.

Authorized dealerNew machines, factory-direct, full manufacturer warranty
Free freight over $500Lower 48 · liftgate available · ship date in 1 business day
Pay your wayCard, Shop Pay Installments, Affirm or ACH/wire
Real experts(844) 455-4327 · Mon–Fri, 9–5 ET
