EKKO EP20Li Lithium Iron Phosphate Pallet Jack 4400 lb Capacity

EKKO EP20Li Lithium Iron Phosphate Pallet Jack 4400 lb Capacity

EKKOModel EP20LiBrand new · Full warrantyBe the first to review

Free freight shipping · ships factory-direct from EKKO. Ship date confirmed by email within 1 business day.

Save $254.91 Save $254.91
$5,098.30
$5,098.30 - $5,098.30
$5,098.30
$4,843.39
$4,843.39 - $4,843.39
$4,843.39

Delivery

How will you unload it? Required
  • Free freightorders over $500
  • Full warrantybrand new
  • 30-day returnsdamage covered
  • Price matchauthorized dealers

Buying for a business? Pay by ACH or wire and skip card fees. Get wire details

EKKO · EP20Li

About the EP20Li

The EKKO EP20Li is a 4,400 lb lithium walkie pallet jack with full-length 27" x 48" forks, steel entry wheels and a built-in charger. It moves dense 48" pallets through receiving, storage and shipping lanes.

A 24V/60Ah LiFePO4 battery powers drive and lift, forks raise to 7.7" and lower to 3.3", and an optional backrest is available for tall loads.

From the manufacturer

The EKKO EP20Li Lithium Iron Phosphate Electric Walkie Pallet Jack is designed with the versatility of a pallet jack and full power lifting and driving. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing.

Made from high-quality steel and components with durable drives, it is built to handle varied floors, heavy use, impacts and frequent direction changes with confidence.

Highlights

  • 4,400 lb load capacity at a 24" load center
  • 27" x 48" forks support the full depth of 48" pallets
  • 7.7" raised height; 3.3" lowered height
  • 24V/60Ah lithium iron phosphate (LiFePO4) battery; built-in charger
  • Full power drive and lift from ergonomic handle controls
  • Steel entry wheels help the forks roll into pallets
  • 55" turning radius; electromagnetic brake
  • Optional load backrest
  • Polyurethane wheels; robotically welded steel
  • EKKO warranty: 3 years on frame, mast and forks; 1 year on components

Specifications

Capacity & lift

Load capacity 4,400 lb
Load center 24 in
Max lift height 7.7 in
Lowered fork height 3.3 in
Lifting speed, laden / unladen 0.8 / 1.1 in/s
Lowering speed, laden / unladen 1.5 / 1.5 in/s

Dimensions

Overall length 67.2 in
Overall width 27.5 in
Wheelbase 53 in
Turning radius 55 in

Power & drive

Battery 24V / 60Ah Lithium (LiFePO4)
Charger Built-in
Drive motor 0.75 kW DC
Gradeability, laden / unladen 8% / 15%
Brake Electromagnetic
Noise level 68 dB(A) at operator

Forks & chassis

Fork length 48 in
Overall fork width 27 in
Single fork width 6 in
Fork thickness 2 in
Wheels Polyurethane
Entry wheels Steel
Load backrest Optional

General

Model EP20Li
Operation Walkie, powered drive and lift
Service weight 680 lb
Warranty 3 yr frame, mast & forks · 1 yr components

Manuals & downloads

⛟Shipping & deliveryFree freight shipping · ship date confirmed in 1 business day

Free freight shipping on orders over $500 to the 48 contiguous states; orders under $500 ship for a flat $150. Remote areas are quoted before you pay.

Machines ship factory-direct. We confirm stock and your ship date by email within 1 business day; transit is typically 3–7 business days and the carrier calls ahead to schedule.

You unload with a forklift or loading dock. No dock? Choose liftgate delivery (+$150) above. Or pick up free at the EKKO warehouse, 1761 W Holt Ave, Pomona, CA.

Inspect the crate before signing, note any damage on the delivery receipt, and report concealed damage within 3 business days.

✓Manufacturer warranty3-year frame, mast & forks · 1-year components · we handle claims for you

Every machine is brand new and covered by the EKKO Advantage Warranty. Coverage for the EP20Li:

  • 3 yearsFrame, mast and forks
  • 1 yearDrive and lift motors, controller, hydraulics, charger and battery (lithium or lead-acid)
  • 30 daysWear items (tires, bulbs, rubber parts)

As an authorized EKKO dealer, we file and manage warranty claims with EKKO for you: send us a photo of the data plate and a photo or video of the problem and we take it from there. Coverage applies to the original purchaser under normal use and scheduled maintenance; wear, overloading, accidents and freight damage aren't covered.

Read the full warranty (PDF) →

↺30-day returnsDamaged or defective on arrival? We cover the freight.

Request a return within 30 days of delivery by phone or email. Equipment must come back in the condition it was received.

Returns of machines working as intended carry a 10% restocking fee and the customer pays return freight. If your equipment arrives damaged or becomes defective within 30 days, we cover return and replacement freight.

Read the full return policy →

$Price match guaranteeFound it lower from an authorized dealer? We'll match it.

If an authorized dealer advertises the identical model, configuration and warranty for less, we'll match that price, as long as it isn't below the manufacturer's minimum advertised price.

Ask before you order or within 7 days of your order date: call (844) 455-4327 or email support@equipmentnation.com with the dealer, link and price. Freight, taxes and fees are excluded.

Price match details →

☎Talk to an equipment expert(844) 455-4327 · Mon–Fri, 9–5 ET

Send us your load weight, lift height, aisle width and door clearances and we'll confirm this is the right machine before you buy. Call (844) 455-4327 or email support@equipmentnation.com.

LITHIUM WALKIE PALLET JACK · EP20Li

4,400 LB ON FULL-LENGTH FORKS

The EKKO EP20Li carries 4,400 lb on 27" x 48" forks and runs on a 24V/60Ah LiFePO4 battery with a built-in charger. Steel entry wheels ease pallet entry.

Capacity4,400 lbPowerLithium 24VLift7.7″
4,400 lbCapacity
Lithium 24VPower
7.7″Lift
27×48″Forks
NewFull manufacturer warranty
EKKO EP20Li Lithium Iron Phosphate Pallet Jack 4400 lb Capacity

BUILT FOR THE JOB

Big battery, full-length forks

The EP20Li is EKKO's 4,400 lb LiFePO4 walkie on full-length 27" x 48" forks. It shares its layout with the 4,000 lb EP18Li and steps up to a 24V/60Ah battery, 50% more amp-hours than the EP18Li's 24V/40Ah pack. Forks raise to 7.7" and lower to 3.3", and the 67.2" chassis turns in 55". Steel entry wheels ease pallet entry, the charger is built in and an optional backrest is available. If you want a Curtis-controlled AC drive and an even larger battery at the same capacity, compare the EP20E-Li.

See full specifications

WHY THE EP20LI

ENGINEERED WHERE IT COUNTS.

01

24V/60Ah LiFePO4 battery

A 24V/60Ah lithium iron phosphate battery powers drive and lift, 50% more amp-hours than the 24V/40Ah battery in the 4,000 lb EP18Li. Lithium also means no battery watering routine.

02

4,400 lb on 48" forks

Rated for 4,400 lb on 27" x 48" forks that support the full depth of 48" pallets. Forks raise to 7.7" and lower to 3.3" for entry.

03

Built-in onboard charger

The charger is built into the jack, so there is no separate charging station or cart to buy and mount. Park it, plug it in and charge at the end of the shift.

04

Steel entry wheels, backrest option

Steel entry wheels help the forks roll into pallets without catching. An optional backrest supports tall loads, and the steel frame is robotically welded for consistent strength.

WHERE IT WORKS

MADE FOR YOUR OPERATION.

Long-shift docks

Keep pallets moving on busy docks with a 24V/60Ah LiFePO4 battery and a charger built into the jack.

48" pallet handling

Move standard 48" pallets with full fork support from tip to heel between receiving, storage and shipping lanes.

Grocery and beverage

Handle dense pallets of canned goods and drinks up to 4,400 lb in distribution warehouses.

Stacked carton loads

Fit the optional backrest to support tall stacks of cartons during travel across the building.

COMPARE SIMILAR MODELS

FIND YOUR EXACT FIT.

EKKO EP20Li Lithium Iron Phosphate Pallet Jack 4400 lb Capacity
This itemEP20Li$4,843.39 		EKKO EP20JLi Full Electric Pallet Jack 4400 lb Capacity  EP20JLi$3,066.89 EKKO EP20E-Li Walkie Pallet Jack 4400lb Capacity  EP20E-Li$7,750.39
Capacity 4,400 lb4,400 lb4,400 lb
Power Lithium 24VLithium 48VLithium 24V
Lift 7.7″7.8″7.9″
Forks 27×48″27×45″27×48″
Shipping FreeFreeFree
You're viewing thisView detailsView details

FROM CHECKOUT TO YOUR DOCK

ORDER. CONFIRM. DELIVER. WORK.

  1. 01

    Order online

    Pick your model and how you'll unload it. Pay by card, financing or ACH.

  2. 02

    Ship date confirmed

    We confirm stock and your ship date by email within 1 business day.

  3. 03

    Freight delivery

    Ships factory-direct from the manufacturer. The carrier calls ahead to schedule.

  4. 04

    Inspect & sign

    Check the crate before signing and note any damage. We handle the rest.

BEFORE YOU BUY

QUESTIONS ABOUT THE EP20LI.

Still unsure? Call (844) 455-4327 or email support@equipmentnation.com. Real people, Mon–Fri.

How does the EP20Li differ from the EP18Li?

Capacity and battery. Both use 27" x 48" forks, steel entry wheels, a built-in charger and an optional backrest. The EP20Li carries 4,400 lb on a 24V/60Ah LiFePO4 battery. The EP18Li carries 4,000 lb on a 24V/40Ah battery. Choose by your heaviest pallet.

How does it compare with the EP20E-Li?

Both carry 4,400 lb on 27" x 48" forks with steel entry wheels and a built-in charger. The EP20Li uses a 24V/60Ah LiFePO4 battery, raises to 7.7" and is 67.2" long. The EP20E-Li adds a Curtis controller and 1.3 kW AC drive, a 24V/100Ah lithium battery and a 7.9" lift in a 71.2" chassis.

How do I charge the EP20Li?

The charger is built into the jack. Park it at a suitable outlet and plug it in to recharge the 24V/60Ah lithium iron phosphate battery. Run-time is not published because it depends on load and distance, so call (888) 378-6244 if you run long shifts.

What pallets fit the EP20Li?

Forks are 27" wide and 48" long, lowering to 3.3" and raising to 7.7". Steel entry wheels near the tips help them roll into pallets. That suits standard 48" pallets with common fork openings. Send us your pallet dimensions if you want us to confirm.

How long until it ships?

We confirm stock and your ship date by email within 1 business day. In-stock units usually leave the warehouse in 2–5 business days, then freight transit takes 3–7 business days.

Is shipping really free?

Yes, on orders over $500 to the 48 contiguous states (orders under $500 ship for a flat $150). You'll need a dock or forklift to unload; otherwise choose liftgate delivery (+$150).

Can I finance it?

Yes. Choose Shop Pay Installments or Affirm at checkout to spread payments out, or call us about ACH/wire for large orders.

CUSTOMER REVIEWS

OWNERS ON THE EP20LI.

No reviews yet. Customer reviews will appear here as they come in.

Questions before you buy? Call (844) 455-4327.

Own the EP20Li? Be the first to review it.

  • How does it handle your loads and lift heights?
  • How does the battery hold up over a full shift?
  • How was ordering, delivery and setup?
