EKKO EK18RR-196Li Reach Truck – 4,000 lb Capacity, 196" Lift, Stand-Up Narrow Aisle, Lithium Battery

EKKOModel EK18RR-196LiBrand new · Full warrantyBe the first to review

Free freight shipping · ships factory-direct from EKKO. Ship date confirmed by email within 1 business day.

Save $2,649.95

$52,999.00

$52,999.00 - $52,999.00

$52,999.00

$50,349.05

$50,349.05 - $50,349.05

$50,349.05

Configure your EK18RR

Compare models

Lift height: 196″

196″ Selected 275″ +$2,850 335″ +$6,650

Battery: Lithium 48V/400Ah

48V/420Ah −$6,650 Lithium 48V/400Ah Selected

Delivery

Freight delivery FREEFree shipping on orders over $500 (lower 48) Pick up at the EKKO warehouse1761 W Holt Ave, Pomona, CA 91768

How will you unload it? Required

Forklift on siteRated for this unit's shipping weight Loading dock48–52″ high, reachable by a full-size freight truck Liftgate delivery +$150Driver lowers it to the ground. Needed for homes and sites without a dock or forklift.

Free freightorders over $500
Full warrantybrand new
30-day returnsdamage covered
Price matchauthorized dealers

Buying for a business? Pay by ACH or wire and skip card fees. Get wire details

EKKO · EK18RR-196Li

About the EK18RR-196Li

The EKKO EK18RR-196Li is the lithium version of the 196" stand-up reach truck. It lifts 4,000 lb to 196" on a triple mast with 53.15" of free lift, reaches 22.44" into the rack and turns in 75", so more floor space goes to racking and less to travel lanes.

A 48V/400Ah lithium battery with a 48V/200A three-phase charger powers a 6 kW German AC drive and 11 kW lift motor. Side-shifting forks, a Curtis controller and electronic power steering give precise placement at height.

From the manufacturer

The EKKO EK18RR-196Li Stand-up Narrow Aisle Reach Truck combines the versatility of a forklift, a reach truck and a walkie stacker. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing.

It is made from high-quality steel and components with durable drives built to withstand daily use, impacts and directional changes. Every unit is robotically welded and uses a Curtis controller, electronic power steering and a German AC drive motor.

Highlights

4,000 lb capacity at a 24" load center
196" maximum lift height on a triple mast with tilt
53.15" free lift
22.44" reach distance
96.42" lowered mast height
Side-shifting forks (3-way valve), 42" long, adjustable to 35.04"
75" turning radius and 54.72" overall width for narrow aisles
6 kW German AC drive motor, 11 kW lift motor, Curtis controller and EPS
48V/400Ah lithium battery and 48V/200A three-phase charger included
EKKO warranty: 3 years on frame, mast and forks; 1 year on components

Specifications

Capacity & lift

Load capacity	4,000 lb
Max lift height	196 in
Free lift	53.15 in
Load center	24 in
Reach distance	22.44 in
Mast	Triple, with tilt

Dimensions

Lowered mast height	96.42 in
Overall length (extended)	102.28 in
Overall width	54.72 in
Turning radius	75 in

Power & drive

Battery	48V / 400Ah lithium
Charger	48V DC / 200A, 440V three-phase input
Drive motor	6 kW German AC, 48V
Lift motor	11 kW, 48V
Steering	Electronic power steering (EPS)
Controller	Curtis

Forks & chassis

Fork size (T × W × L)	1.58 × 4.72 × 42 in
Adjustable fork width	7.9–35.04 in
Side shift	Yes, 3-way valve
Wheels	Polyurethane

General

Model	EK18RR-196Li
Operation	Stand-up rider
Service weight	8,700 lb
Warranty	3 yr frame, mast & forks · 1 yr components

Manuals & downloads

⛟Shipping & deliveryFree freight shipping · ship date confirmed in 1 business day

Free freight shipping on orders over $500 to the 48 contiguous states; orders under $500 ship for a flat $150. Remote areas are quoted before you pay.

Machines ship factory-direct. We confirm stock and your ship date by email within 1 business day; transit is typically 3–7 business days and the carrier calls ahead to schedule.

You unload with a forklift or loading dock. No dock? Choose liftgate delivery (+$150) above. Or pick up free at the EKKO warehouse, 1761 W Holt Ave, Pomona, CA.

Inspect the crate before signing, note any damage on the delivery receipt, and report concealed damage within 3 business days.

✓Manufacturer warranty3-year frame, mast & forks · 1-year components · we handle claims for you

Every machine is brand new and covered by the EKKO Advantage Warranty. Coverage for the EK18RR-196Li:

3 yearsFrame, mast and forks
1 yearTransmission, drive and lift motors, controllers, charger, hydraulic pump, sensors
Up to 5 yearsLithium battery on EKKO's designated lithium models (1 year on other batteries)
6 monthsLabor on specified models, with EKKO's prior approval
30 daysWear items (tires, bulbs, rubber parts)

As an authorized EKKO dealer, we file and manage warranty claims with EKKO for you: send us a photo of the data plate and a photo or video of the problem and we take it from there. Coverage applies to the original purchaser under normal use and scheduled maintenance; wear, overloading, accidents and freight damage aren't covered.

Read the full warranty (PDF) →

↺30-day returnsDamaged or defective on arrival? We cover the freight.

Request a return within 30 days of delivery by phone or email. Equipment must come back in the condition it was received.

Returns of machines working as intended carry a 10% restocking fee and the customer pays return freight. If your equipment arrives damaged or becomes defective within 30 days, we cover return and replacement freight.

Read the full return policy →

$Price match guaranteeFound it lower from an authorized dealer? We'll match it.

If an authorized dealer advertises the identical model, configuration and warranty for less, we'll match that price, as long as it isn't below the manufacturer's minimum advertised price.

Ask before you order or within 7 days of your order date: call (844) 455-4327 or email support@equipmentnation.com with the dealer, link and price. Freight, taxes and fees are excluded.

Price match details →

☎Talk to an equipment expert(844) 455-4327 · Mon–Fri, 9–5 ET

Send us your load weight, lift height, aisle width and door clearances and we'll confirm this is the right machine before you buy. Call (844) 455-4327 or email support@equipmentnation.com.

LITHIUM STAND-UP REACH TRUCK · EK18RR-196Li

196" REACH TRUCK, LITHIUM POWERED

The EKKO EK18RR-196Li lifts 4,000 lb to 196" with 22.44" of reach. It runs on a 48V/400Ah lithium battery with a 48V/200A three-phase charger.

Capacity4,000 lbLift196″Reach22.44″

4,000 lbCapacity

196″Lift

22.44″Reach

Lithium 48V/400AhBattery

NewFull manufacturer warranty

BUILT FOR THE JOB

Narrow-Aisle Density, Lithium Uptime

The EK18RR-196Li is the lithium version of the 196" stand-up reach truck. It shares the EK18RRL's 4,000 lb capacity, 22.44" reach, triple mast with 53.15" of free lift and 75" turning radius. In place of the 48V/420Ah battery it carries a 48V/400Ah lithium pack with a 48V/200A three-phase charger, and at 8,700 lbs it is 300 lbs lighter. Lithium also means no battery watering routine. It suits narrow-aisle operations that want dense racking up to 196" on lithium power.

See full specifications

WHY THE EK18RR-196LI

ENGINEERED WHERE IT COUNTS.

4,000 lb to 196"

A triple mast lifts 4,000 lb at a 24" load center to 196", with 53.15" of free lift and mast tilt. The 22.44" reach sets pallets into deep rack positions.

48V/400Ah Lithium Battery

The lithium pack is paired with a 48V/200A three-phase charger. It drives a 48V/6000W German AC drive motor and a 48V/11000W lift motor, and it needs no watering.

75" Turning Radius

A 75" turning radius, 54.72" width and 102.28" overall length suit narrow aisles, so you can add racking rows instead of leaving wide lanes for counterbalanced forklifts.

Side Shift and EPS

Side-shifting forks on a 3-way valve and EPS steering give precise pallet placement. The stand-up compartment offers clear visibility up the mast, and polyurethane wheels ride on robotically welded steel.

WHERE IT WORKS

MADE FOR YOUR OPERATION.

Multi-Shift Distribution

Run narrow-aisle put-away in busy distribution centers on a lithium pack with no battery watering routine.

3PL Storage

Increase pallet positions per square foot and handle high-volume inbound and outbound moves in shared warehouses.

Food and Beverage

Rack case-packed product up to 196" in dense indoor storage while keeping aisles tight and traffic moving.

Retail Replenishment

Feed store-bound orders from high racking in regional retail distribution centers with steady, all-day productivity across shifts.

COMPARE SIMILAR MODELS

FIND YOUR EXACT FIT.

	This itemEK18RR-196Li$50,349.05	ER15-138Li$24,224.05	EH15T$22,799.05	EH15TH$24,224.05
Capacity	4,000 lb	3,300 lb	3,300 lb	3,300 lb
Lift	196″	138″	138″	216″
Reach	22.44″	19.7″	19.7″	19.7″
Battery	Lithium 48V/400Ah	Lithium 24V/200Ah	24V/270Ah	24V/270Ah
Shipping	Free	Free	Free	Free
	You're viewing this	View details	View details	View details

FROM CHECKOUT TO YOUR DOCK

ORDER. CONFIRM. DELIVER. WORK.

01
Order online
Pick your model and how you'll unload it. Pay by card, financing or ACH.
02
Ship date confirmed
We confirm stock and your ship date by email within 1 business day.
03
Freight delivery
Ships factory-direct from the manufacturer. The carrier calls ahead to schedule.
04
Inspect & sign
Check the crate before signing and note any damage. We handle the rest.

BEFORE YOU BUY

QUESTIONS ABOUT THE EK18RR-196LI.

Still unsure? Call (844) 455-4327 or email support@equipmentnation.com. Real people, Mon–Fri.

How is the EK18RR-196Li different from the EK18RRL?

Both lift 4,000 lb to 196" with 22.44" of reach and a 75" turning radius. The EK18RR-196Li uses a 48V/400Ah lithium battery with a 48V/200A three-phase charger. The EK18RRL uses a 48V/420Ah battery with a 48V/65A charger. The lithium model weighs 8,700 lbs, compared with 9,000 lbs.

What power do I need to charge the EK18RR-196Li?

The included 48V/200A charger is a three-phase unit, listed at 440V input. Confirm that your building has three-phase service near the charging area before delivery. Call (888) 378-6244 and our team will confirm the charger input with EKKO and walk through the requirements with you.

Will the EK18RR-196Li fit through my doors?

The lowered mast height is 96.42", and overall width is 54.72". Compare those numbers with your doorways, sprinkler lines and overhead door tracks. Remember that a raised load can add height. We are happy to review your clearances if you call with measurements.

What forks come on the EK18RR-196Li?

Forks are 42" long, measuring 1.58" x 4.72", and adjust out to 35.04" wide. Side shift on a 3-way valve lets the operator align pallets without moving the truck. Rated capacity is 4,000 lb at a 24" load center. Mast tilt helps at height.

How long until it ships?

We confirm stock and your ship date by email within 1 business day. In-stock units usually leave the warehouse in 2–5 business days, then freight transit takes 3–7 business days.

Is shipping really free?

Yes, on orders over $500 to the 48 contiguous states (orders under $500 ship for a flat $150). You'll need a dock or forklift to unload; otherwise choose liftgate delivery (+$150).

Can I finance it?

Yes. Choose Shop Pay Installments or Affirm at checkout to spread payments out, or call us about ACH/wire for large orders.

CUSTOMER REVIEWS

OWNERS ON THE EK18RR-196LI.

No reviews yet. Customer reviews will appear here as they come in.

Questions before you buy? Call (844) 455-4327.

Own the EK18RR-196Li? Be the first to review it.

How does it handle your loads and lift heights?
How does the battery hold up over a full shift?
How was ordering, delivery and setup?
