EKKO EK18RFL Stand-up Rider Forklift, 4000 lb Capacity, 189" Lift Height 48V

EKKOModel EK18RFLBrand new · Full warrantyBe the first to review

Free freight shipping · ships factory-direct from EKKO. Ship date confirmed by email within 1 business day.

Save $1,889.95

$37,799.00

$37,799.00 - $37,799.00

$37,799.00

$35,909.05

$35,909.05 - $35,909.05

$35,909.05

Configure your EK18RFL

Compare models

Lift height: 189″

189″ Selected 216″ +$1,330

Power: Lead-acid 48V

Lead-acid 48V Selected Lithium 48V 216″ only

Delivery

Freight delivery FREEFree shipping on orders over $500 (lower 48) Pick up at the EKKO warehouse1761 W Holt Ave, Pomona, CA 91768

How will you unload it? Required

Forklift on siteRated for this unit's shipping weight Loading dock48–52″ high, reachable by a full-size freight truck Liftgate delivery +$150Driver lowers it to the ground. Needed for homes and sites without a dock or forklift.

Free freightorders over $500
Full warrantybrand new
30-day returnsdamage covered
Price matchauthorized dealers

Buying for a business? Pay by ACH or wire and skip card fees. Get wire details

EKKO · EK18RFL

About the EK18RFL

Step on, lift and go with the EKKO EK18RFL, a stand-up rider forklift that lifts 4,000 lb to 189" (15.75 ft) with 52.2" of free lift. Side shifting forks, an 82.6" lowered mast and a 58.5" turning radius make it a quick, compact truck for docks and mid-height racking.

A 48V/420Ah battery powers a German AC drive motor through a Curtis Instruments controller, with hydraulic steering, solid cushion load tires and polyurethane drive tires for smooth indoor floors. A 480V 3-phase charger is standard.

From the manufacturer

The EKKO EK18RFL stand-up rider forklift is designed for all of your material handling demands. It is ideal for loading and unloading trucks, loading docks, stock rooms, manufacturing floors and warehousing.

It is made from high-quality steel and components, with durable drives built for daily use, impacts and constant directional changes.

Highlights

Load capacity 4,000 lb at a 24" load center
189" maximum lift height with 52.2" free lift
Stand-up rider design with a 9.1" step-on height
Side shifting forks, adjustable 9.4"–35.6", 45.3" long
48V/420Ah battery included
480V 3-phase charger standard; 220V 3-phase and 110V single-phase optional
German AC drive motor with Curtis Instruments controller
Hydraulic steering, 58.5" turning radius, 10.5 ft aisle width requirement
Solid cushion load tires and polyurethane drive tires
3 Year Limited Warranty

Specifications

Capacity & lift

Load capacity	4,000 lb
Load center	24 in
Max lift height	189 in
Free lift	52.2 in
Extended mast height	220.9 in
Mast tilt (forward/back)	3° / 5°
Lift speed (laden/unladen)	9.8 / 15.7 in/s
Lowering speed (laden/unladen)	9.4 / 10.2 in/s

Dimensions

Lowered mast height	82.6 in
Overhead guard height	90.1 in
Step-on platform height	9.1 in
Overall length	117.8 in
Length to fork face	72.5 in
Overall width	42.5 in
Wheelbase	48.8 in
Min. turning radius	58.5 in
Aisle width requirement	10.5 ft
Ground clearance (under mast / minimum)	2.95 / 3.86 in

Power & drive

Battery	48V / 420Ah lead-acid (included)
Battery weight	1,570 lb
Charger	48V / 65A, 480V 3-phase (standard)
Optional chargers	220V 3-phase or 110V single-phase (extra cost)
Drive motor	German AC, 6 kW (60-min rating)
Lift motor	7.7 kW
Controller	Curtis Instruments
Travel speed (laden/unladen)	7.5 / 8.1 mph
Gradeability (laden/unladen)	6% / 10%
Service brake	Hydraulic
Noise at operator's ear	≤70 dB(A)

Forks & chassis

Side shift	Yes
Fork size (T × W × L)	1.58 × 4.72 × 45.28 in
Adjustable fork width	9.4–35.6 in
Drive tire	16 × 7-10.5 in polyurethane
Load tires	13.5 × 5.2 in solid cushion
Wheels (drive / load)	1 / 2
Steering	Hydraulic

General

Model	EK18RFL
Service weight (with battery)	7,870 lb
Warranty	3 Year Limited Warranty

Manuals & downloads

EKKO Advantage Warranty

⛟Shipping & deliveryFree freight shipping · ship date confirmed in 1 business day

Free freight shipping on orders over $500 to the 48 contiguous states; orders under $500 ship for a flat $150. Remote areas are quoted before you pay.

Machines ship factory-direct. We confirm stock and your ship date by email within 1 business day; transit is typically 3–7 business days and the carrier calls ahead to schedule.

You unload with a forklift or loading dock. No dock? Choose liftgate delivery (+$150) above. Or pick up free at the EKKO warehouse, 1761 W Holt Ave, Pomona, CA.

Inspect the crate before signing, note any damage on the delivery receipt, and report concealed damage within 3 business days.

✓Manufacturer warranty3-year frame, mast & forks · 1-year components · we handle claims for you

Every machine is brand new and covered by the EKKO Advantage Warranty. Coverage for the EK18RFL:

3 yearsFrame, mast and forks
1 yearTransmission, drive and lift motors, controllers, charger, hydraulic pump, sensors
Up to 5 yearsLithium battery on EKKO's designated lithium models (1 year on other batteries)
6 monthsLabor on specified models, with EKKO's prior approval
30 daysWear items (tires, bulbs, rubber parts)

As an authorized EKKO dealer, we file and manage warranty claims with EKKO for you: send us a photo of the data plate and a photo or video of the problem and we take it from there. Coverage applies to the original purchaser under normal use and scheduled maintenance; wear, overloading, accidents and freight damage aren't covered.

Read the full warranty (PDF) →

↺30-day returnsDamaged or defective on arrival? We cover the freight.

Request a return within 30 days of delivery by phone or email. Equipment must come back in the condition it was received.

Returns of machines working as intended carry a 10% restocking fee and the customer pays return freight. If your equipment arrives damaged or becomes defective within 30 days, we cover return and replacement freight.

Read the full return policy →

$Price match guaranteeFound it lower from an authorized dealer? We'll match it.

If an authorized dealer advertises the identical model, configuration and warranty for less, we'll match that price, as long as it isn't below the manufacturer's minimum advertised price.

Ask before you order or within 7 days of your order date: call (844) 455-4327 or email support@equipmentnation.com with the dealer, link and price. Freight, taxes and fees are excluded.

Price match details →

☎Talk to an equipment expert(844) 455-4327 · Mon–Fri, 9–5 ET

Send us your load weight, lift height, aisle width and door clearances and we'll confirm this is the right machine before you buy. Call (844) 455-4327 or email support@equipmentnation.com.

STAND-UP RIDER FORKLIFT, 48V · EK18RFL

STAND-UP RIDER AT 189" LIFT

The EKKO EK18RFL is a 4,000 lb stand-up rider forklift with a 189" lift, 52.2" of free lift and side shifting forks, powered by a 48V/420Ah battery.

Capacity4,000 lbLift189″PowerLead-acid 48V

4,000 lbCapacity

189″Lift

Lead-acid 48VPower

CushionTires

NewFull manufacturer warranty

BUILT FOR THE JOB

The lower-mast stand-up rider

The EK18RFL is the lowest-mast, lowest-priced model in EKKO's EK18RF stand-up rider family. It is built for docks and warehouses where operators step on and off all day and racking tops out around 15.75 ft. It lifts 4,000 lb to 189" with 52.2" of free lift, and its mast stands 82.6" when lowered, 9.2" lower than the EK18RF. A 48V/420Ah battery powers a German AC drive motor through a Curtis Instruments controller, and hydraulic steering keeps handling light. For 216" of lift, step up to the EK18RF or EK18RF-Li.

See full specifications

WHY THE EK18RFL

ENGINEERED WHERE IT COUNTS.

4,000 lb to 189"

Lift 4,000 lb at a 24" load center to 189", or 15.75 ft, with 52.2" of free lift. Side shifting forks and 3-degree forward, 5-degree back tilt help place each pallet cleanly.

48V/420Ah Battery Included

The included 48V/420Ah battery powers a 6 kW German AC drive motor and a 7.7 kW lift motor through a Curtis Instruments controller. A 480V 3-phase charger is standard, with 220V and 110V options.

Stand-Up Rider Design

The operator stands in the compartment with a 9.1" step-on height, so stepping on and off at docks and staging lanes is quick. The truck turns in a 58.5" radius and needs a 10.5 ft aisle.

Cushion and Poly Tires

Solid cushion load tires and a polyurethane drive tire are built for smooth indoor concrete. Robotically welded steel construction stands up to frequent impacts and constant direction changes.

WHERE IT WORKS

MADE FOR YOUR OPERATION.

Cross-dock transfers

Transfer pallets between inbound and outbound trailers with frequent stops and quick step-on, step-off operation.

Mid-height racking

Put away 4,000 lb pallets on beams up to 189" in distribution centers with standard racking heights.

Trailer loading

Load and unload trailers at indoor docks, using 52.2" of free lift to stack inside without raising the mast.

Staging and replenishment

Shuttle pallets between staging lanes and pick areas all shift, stepping off to scan and check loads.

COMPARE SIMILAR MODELS

FIND YOUR EXACT FIT.

	This itemEK18RFL$35,909.05	EK18AT-212Li$34,199.05	EK20GT-Li$31,919.05
Capacity	4,000 lb	4,000 lb	4,000 lb
Lift	189″	212″	185″
Power	Lead-acid 48V	Lithium 48V	Lithium 80V
Tires	Cushion	Solid pneumatic	Solid pneumatic
Shipping	Free	Free	Free
	You're viewing this	View details	View details

FROM CHECKOUT TO YOUR DOCK

ORDER. CONFIRM. DELIVER. WORK.

01
Order online
Pick your model and how you'll unload it. Pay by card, financing or ACH.
02
Ship date confirmed
We confirm stock and your ship date by email within 1 business day.
03
Freight delivery
Ships factory-direct from the manufacturer. The carrier calls ahead to schedule.
04
Inspect & sign
Check the crate before signing and note any damage. We handle the rest.

BEFORE YOU BUY

QUESTIONS ABOUT THE EK18RFL.

Still unsure? Call (844) 455-4327 or email support@equipmentnation.com. Real people, Mon–Fri.

How does the EK18RFL compare with the EK18RF?

Both are 4,000 lb stand-up rider forklifts with a 48V/420Ah battery, German AC drive motor, Curtis controller and side shifting forks. The EK18RFL lifts to 189" with an 82.6" lowered mast and 52.2" of free lift. The EK18RF lifts to 216" with a 91.8" mast and 61.3" of free lift. The EK18RFL costs less.

What charger comes with the EK18RFL?

EKKO lists a 48V/65A charger that runs on 480V 3-phase power as standard. Optional 220V 3-phase or 110V single-phase chargers are available at extra cost. Call (888) 378-6244 and we will confirm the charger that matches your facility's electrical service.

How much aisle space does the EK18RFL need?

EKKO lists a 10.5 ft aisle width requirement and a 58.5" minimum turning radius. The truck is 42.5" wide and 117.8" long with forks, or 72.5" to the fork face. Send us your rack and aisle layout and we will confirm the fit before you buy.

What floors is the EK18RFL built for?

It uses solid cushion load tires and a polyurethane drive tire, which are best on smooth indoor concrete. It suits warehouses, distribution centers and indoor docks. For rough outdoor yards, look at a solid pneumatic forklift instead. We can help you choose.

How long until it ships?

We confirm stock and your ship date by email within 1 business day. In-stock units usually leave the warehouse in 2–5 business days, then freight transit takes 3–7 business days.

Is shipping really free?

Yes, on orders over $500 to the 48 contiguous states (orders under $500 ship for a flat $150). You'll need a dock or forklift to unload; otherwise choose liftgate delivery (+$150).

Can I finance it?

Yes. Choose Shop Pay Installments or Affirm at checkout to spread payments out, or call us about ACH/wire for large orders.

CUSTOMER REVIEWS

OWNERS ON THE EK18RFL.

No reviews yet. Customer reviews will appear here as they come in.
